SHERP Ark

Inspired by the success and capabilities of the SHERP Pro and SHERP Pickup, the envelope was pushed to develop the SHERP Ark. The SHERP Ark is even more advanced and will be a reliable companion even in the most difficult conditions with being able to overcome snow, sand, rocks, mud, swamp, ice, and water.

There is nothing like the SHERP Ark in the world:

  • Travels on grass, forest, sand, peat, moor, marsh, beach, dunes, rocks, scree, gravel, snow, ice
  • Swims in pond, lake, river, river delta, sandbanks, shore, intertidal coasts, ocean and sea coast, shoals, frozen waters
  • Climbs out of the water onto ice
  • Overcomes 5-feet high obstacles and trench crossing 6.5-feet
  • Traverses 40-degree (88%) slopes
  • Transports 7500 lb

Specs

Engine

  • Engine Type

    Doosan D24 Tier 4 Final

  • Engine Power

    74 HP @ 2600 RPM
    206ft/lbs. of Torque @1600 RPM

  • Fuel Type

    Diesel

  • Cylinders

    4

  • Fuel Economy

    2-3 gal/h

Performance

  • Operating Speed

    Maximum (in top gear): 25 mph
    Minimum (in low gear): 0.9 mph
    On water: 3.7 mph

Drivetrain

  • Transmission

    5-speed manual

  • Clutch

    SACHS

  • Gears

    Maximum (in top): 18.6 mph
    Minimum (in low): 0.6 mph

  • Chassis

    Steel (frame and bottom, hot dipped galvanized) and aluminum (cabin)

  • Suspension

    Pneumatic Circulating

Brakes

  • Parking Brake

    Independent

Wheels & Tires

  • Tires

    1600 х 600 х 25 (63 x 23 x 25 in), tubeless, ultra low pressure

  • Ground Clearance

    21.65 in - 23.62 in

  • Length

    380 in (9632 mm)

  • Width

    100 in (2520 mm)

  • Height

    102 in (2605 mm)

  • Platform length (rear section)

    189 in (4800 mm)

  • Platform width (rear section)

    87 in (2210 mm)

Capacities

  • Cargo Capacity

    7,500 lb (3,400 kg) (880 lb (400 kg) in front section and 6,600 lb (3,000 kg) in rear section)

  • Fuel Capacity

    63 gal (240 L) (8 gal (30 L) in a front section, 55 gal (210 L) in rear section)

  • Seating Capacity

    21 passengers (3 in the front section and 18 in the rear section) plus the driver.

Weights

  • Dry weight

    10,500 lb (4,300 kg)
